| Product Name | 321 Stainless Steel Wire |
| Standard | ASTM A580, ASTM A313, UNS S32100 |
| Material | 321 |
| Technique | Cold drawn, Hot rolled, Cold rolled and Others. |
| Common Size Specs | Diameter range: 0.2mm – 6.0mm | Hot-selling: 0.5mm, 1.0mm, 1.6mm, 2.5mm, 4.0mm Standard coil weight: 50kg / 100kg; custom straight cut wire available |
| Surface Treatment | Bright Annealed BA Finish; Pickled Matte Finish; Lubricated drawing surface; Anti-rust oil coating |
| Available Material Tempers |
Soft Annealed; Full Hard Temper |
| Origin | China |
| Price Terms | EXW, FOB, CIF, CRF, CNF or others |
| Payment Term | TT, LC, Cash, Paypal, DP, DA, Western Union or Others. |
| Packaging | Bundle, PVC Bag, Nylon Belt, Cable Tie, Standard export seaworthy package or as Request. |
| Processing Service | Bending, Welding, Decoiling, Punching, Cutting and Others. |
| Tolerance | ±1% |
| Exported to | Vietnam, Thailand, Malaysia; Germany, Poland; UAE, Saudi Arabia |
| Core Strengths | Titanium additive suppresses chromium carbide precipitation, no grain corrosion after long high-heat service Retains tensile strength under cyclic heating up to 900°C, far more stable than 304 wire Smooth uniform roundness reduces breakage during automatic mesh weaving & spring coiling Excellent weldability without post-weld heat treatment for thermal equipment assembly Stable anti-oxidation performance for furnace, exhaust and heat exchange environments |
| Main Applications | High-temperature furnace filter mesh, heat-resistant industrial springs, automotive exhaust hardware, thermal sensor leads, boiler binding wire, chemical heat exchanger components |
Haiwo supplies premium quality stainless steel coil wire products for all importers, distributors and project managers, inquire us now!
Composition of Stainless Steel
Steel is an alloy of iron and carbon. Stainless steels are steels containing at least 10.5% chromium, less than 1.2% carbon and other alloying elements. Stainless steel’s corrosion resistance and
mechanical properties can be further enhanced by adding other elements, such as nickel, molybdenum, titanium, niobium, manganese, etc.
| Grade | C | Si | Mn | P | S | Cr | Ni | Mo | N | Cu |
| 201 | ≤0.15 | ≤0.75 | 5.5~7.5 | ≤0.060 | ≤0.03 | 16.00~18.00 | 3.5~5.5 | - | - | 0.08 |
| 202 | ≤0.15 | ≤1.00 | 7.5~10.00 | ≤0.060 | ≤0.03 | 17.00~19.00 | 4.0~6.0 | - | ≤0.25 |
|
| 301 | ≤0.15 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 16.00~18.00 | 6.00~8.00 | - |
|
|
| 302 | ≤0.15 | ≤1.00 | ≤2.00 | ≤0.035 | ≤0.03 | 17.00~19.00 | 8.00~10.00 | - |
|
|
| 304 | ≤0.07 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 18.00~20.00 | 8.00~10.50 | - |
|
|
| 304L | ≤0.030 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 18.00~20.00 | 9.00~13.00 | - |
|
|
| 310S | ≤0.08 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 24.00~26.00 | 19.00~22.00 | - |
|
|
| 316 | ≤0.08 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 16.00~18.00 | 10.00~14.00 | 2.00~3.00 |
|
|
| 316L | ≤0.03 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 16.00~18.00 | 12.00~15.00 | 2.00~3.00 |
|
|
| 321 | ≤0.08 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 17.00~19.00 | 9.00~13.00 | - |
|
|
| 430 | ≤0.12 | ≤0.75 | ≤1.00 | ≤0.040 | ≤0.03 | 16.00~18.00 |
| - |
|
|
| 2205 | ≤0.03 | ≤1.00 | ≤2.00 | ≤0.030 | ≤0.015 | 22.00~23.00 | 4.5~6.5 | 2.5~3.5 |
|
|
| 2507 | ≤0.03 | ≤0.08 | ≤1.20 | ≤0.035 | ≤0.015 | 24.00~26.00 | 6.00~8.00 | 3.0~5.0 |
|
|
| 904L | ≤0.02 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.035 | 19.00~23.00 | 23.00~28.00 | 4.0~5.0 |
| 1.0~2.0 |
| INCONEL028 | ≤0.03 | ≤1.00 | ≤2.50 | ≤0.030 | ≤0.030 | ≤28.0 | ≤34.0 | ≤4.0 |
| ≤1.4 |
| MONEL400 | ≤0.30 | ≤0.5 | ≤2.00 | - | ≤0.024 | - | ≥63.0 | - |
| ≤34.0 |
| INCONEL800 | ≤0.10 | ≤1.00 | ≤1.50 | - | ≤0.015 | ≤23.0 | ≤35 | 4.0~5.0 | - | ≤0.75 |
